Ropewalk Generation Settings Explained: What Every Control Actually Does

Nano Banana 2 renders a 1K image for 270 coins — switch Resolution to 4K in the same panel and the price jumps to 605, because you're asking for roughly four times the pixels. That panel, tucked behind a small gear icon next to the Chat composer, is where you dial in exactly what a model produces before you hit send, and this guide walks through every control in it.

By Ropewalk Team. Tested on 2026-09-04 directly in the Chat composer on Nano Banana 2 and Google Veo 3.1 Fast.

The Quick Answer

Select a model in Chat, then click the gear icon that appears next to the composer to open Generation Settings. Universal controls (resolution, aspect ratio) sit at the top; model-specific controls (duration, audio, reference images) sit below, and they change what the model actually produces — the live cost badge is just a secondary readout. Settings save per model, so you only configure them once.

Step 1: Select a model to reveal the gear icon

The Generation Settings panel is per-model, so it only exists once you've picked one. Open Chat or Canvas, click the model selector at the bottom-left of the composer (it opens a tabbed list — All, Text, Image, Video, Audio, 3D), and choose a model. The moment the model loads into the composer, a small gear icon appears directly above it, at the top-left corner of the input box. Before you select a model, that space is empty — there's nothing to configure yet. On 2026-09-04 this was tested by selecting Nano Banana 2 from the Image tab; the gear icon rendered within about a second of the model attaching to the composer.

Step 2: Open the panel and read the header

Click the gear icon and a card expands above the composer. The header carries four things: the model's icon and name, a one-line description, a small media-type icon showing what it outputs (image, video, audio), and a live cost badge showing the coins one generation currently costs. For Nano Banana 2 at its default settings, that badge read 270 coins when confirmed live on 2026-09-04. This header is worth reading before you touch any control below it, because the badge updates instantly as you change settings — it's a running total, not a static price.

Step 3: Set the universal controls — resolution and aspect ratio

Every image and video model shares two controls: a quality/resolution select and an aspect ratio select. On Nano Banana 2, Resolution offers 1K, 2K, and 4K — each step up asks the model for more detail and a larger file, which is why 1K costs 270 coins against 605 for 4K, a 2.2× jump. Aspect Ratio defaults to "Match Input" (it mirrors whatever reference image you attach) but can be locked to a fixed ratio — 1:1, 2:3, 3:2 and several others were available in the dropdown when tested on 2026-09-04. Pick 4K when the output is the final asset (a print, a hero banner); pick 1K when you're iterating on a prompt and don't want to pay for pixels you'll throw away.

Step 4: Watch the cost badge react to your choice

Watching the cost badge react is the fastest way to understand what a setting actually does: change it and watch the header. Switching Resolution from 1K to 4K on Nano Banana 2 moved the badge from 270 to 605 coins in the same second (a 2.2× jump, confirmed 2026-09-04), no page reload, no confirmation click. The badge is a readout of the choice you just made, not the reason to make it — treat it as confirmation that a heavier setting was applied, not as the control's purpose. The same live-update behavior applies to every select in the panel, including the checkboxes for Google Image Search and Web Search grounding.

Step 5: Learn the model-specific controls on a video model

Switch the composer to a video model — Google Veo 3.1 Fast, tested here — and the panel reshapes around what video actually needs. Duration offers 5 or 10 seconds, and it roughly doubles the cost badge (3,000 coins for 5 seconds, 6,000 for 10), since you're asking for twice the footage. Audio offers "With audio" or "Without audio (cheaper)" — this is not just a discount toggle, it changes whether the rendered clip has a synchronized soundtrack at all, so pick it based on whether you're producing a silent b-roll clip or a finished piece with sound.

Step 6: Use the advanced controls when the default isn't enough

Below Duration and Audio, Veo 3.1 Fast exposes a Negative Prompt field (describe what to exclude from the output), a Seed field defaulting to 0 (set a specific number to reproduce a result, leave it at 0 for a fresh random result each time), and an "Enable prompt optimizer" checkbox that rewrites your prompt for the model before generating — on by default, confirmed 2026-09-04. Nano Banana 2 has an equivalent pair of grounding checkboxes instead: Google Image Search grounding pulls in web images as visual context, and Google Web Search grounding lets the model reference real-time facts like weather or scores. None of these are required reading for a first generation, but they're the difference between a lucky result and a repeatable one.

Step 7: Know what a locked tier looks like, and that settings persist

On an account without access to a given tier, selecting a gated option (a higher resolution or quality tier reserved for paid plans) opens an upgrade prompt instead of applying the change — that's expected behavior, not a bug, and the setting snaps back until you upgrade or pick something your plan covers. It's easy to mistake this for a broken dropdown the first time it happens, since nothing in the panel visually marks a tier as locked until you actually click it — the upgrade prompt is the only signal. One more thing worth knowing before you start generating, verified 2026-09-04: every setting in this panel is saved per model. Change Nano Banana 2's default to 4K once, and the next time you select Nano Banana 2 in any chat, it opens already set to 4K — you configure a model once, not every message.

FAQ

Why is there no gear icon next to my composer?
The gear icon only renders once a model is attached to the message. Open the model selector at the bottom-left of the composer and pick one — the icon appears immediately above the input box in under 1 second, confirmed 2026-09-04.

I picked a resolution and nothing happened except a popup — is that broken?
No — that's the premium gate. Higher quality tiers on some models are reserved for paid plans, and picking a locked one opens an upgrade prompt instead of applying the setting. Choose an available tier or upgrade to unlock it.

Do I need to reconfigure settings every time I open a new chat?
No. Generation Settings save per model, not per chat. Whatever you last set for a given model — resolution, duration, audio, grounding checkboxes — is already applied the next time you select that same model, in any chat.
